Chapter 3 Serial Configuration
Output-3
Format: <K'output on,polarity,pulse width,# before output>
output on (mode):
0 = Mismatch or Noread
1 = Match (or Good Read)
2 = Mismatch
3 = Noread
Example: To set Output-3 to Mismatch and change Pulse Width to 40 ms, send
<K'2,0,4> or <K'2,,4>.
Bar Code Output
Format: <Klstatus,when to output>
status: when to output:
0 = Disabled 0 = As Soon As Possible
1 = Match 1 = End of Read Cycle
2 = Mismatch
3 = Good Read
Example: To set When to Output to End of Read Cycle, send <Kl3,1>.
Scanner Output Status Request
Format: <KX?>
Returns status of each command in the Scanner Output group.
3-20
MS-850 Raster Scanner User's Manual
polarity: pulse width:
0 = Negative Default is 5
1 = Positive (50 ms).
1 to 255
# before
output:
Default is 1.
1 to 255
