Chapter 3 Serial Configuration

Diagnostics

Warning Messages Status
Format: <K"status,laserhi,laserlo,novram message>
status: laserhi:
0 = Disabled 0 = Disabled
1 = Enabled 1 = Enabled
Example: To enable Diagnostics and disable laserhi, send <K"1,0>.
Laser Current
You can set messages for high and low current thresholds.
High Laser Current
Format: <K;message>
message:
Any 1 to 7 character ASCII string except NUL, <, or >.
Default is HI-LASR.
Example: To change the message to HI-CURR, send <K;HI-CURR>.
Low Laser Current
Format: <K:message>
message:
Any 1 to 7 character ASCII string except NUL, <, or >.
Default is LO-LASR.
Example: To change the message to LO-CURR<K:LO-CURR>.
Operating Temperature
High Temperature Threshold (deg. C)
Format: <K+degrees,message>
degrees: message:
0 to 50, zero disables.
default is 50
Example: To change the temperature to 45 and message to MAX-TMP,
send <K+,MAX-TMP>.
3-24
MS-850 Raster Scanner User's Manual
laserlo: novram corrupt warning:
0 = Disabled 0 = Disabled
1 = Enabled 1 = Enabled
Any 1 to 7 character ASCII string except NUL, <, or >.
Default is HI-TEMP.
