Chapter 2 Menu Configuration
Check Digit
Default: Disabled
Options: Disabled, Enabled
I 2 of 5 uses a Modulus 10 check digit.
Check Digit Output
Default: Disabled
Options: Disabled, Enabled
When enabled, the check digit character is sent along with the label data. When dis-
abled, label data is sent without the check digit.
Code Length #1
Default: 10
Options: 0 to 64, even. If you enter an odd number the scanner will use the next
lower number.
With I 2 of 5, two code lengths can be defined. When using only one label length in an
application, we recommend setting Code Length #2 to 0 to ensure data integrity. If a
check digit is used, it must be included in the code length count.
Code Length #2
Default: 6
Options: 0 to 64, even. (If you enter an odd number the scanner will use the next
lower number.)
If using a second label, you may also specify a zero or any even code length from 2 to
30. If not using a second label, set Code Length #2 to 0 to ensure data integrity.
PDF 417
Default: Disabled
Options: Disabled, Enabled
A two-dimensional, multi-row (3 to 90), continuous, variable length symbology that
has high data capacity of storing up to about 1,800 printable ASCII characters or
1,100 binary character per symbol. Each symbol character consists of 4 bars and 4
spaces in a 17-module structure.
Raster Sweeps Before Decode Attempt
Default: 0 (zero)
Options: 0 to 4
Allows you to set the number of sweeps the raster mirror makes before the scanner
attempts to decode the bar code data. A sweep is one pass of the raster, up or down.
