Step 7 Determine Raster Height and Sweep Rate

You need to know the raster height, the zone perpendicular to the direction the label
is moving that the labels will appear, and the raster sweep rate, the number of
passes per second, up or down, describing the raster image.
If you know raster height, along with scan width, read range, and the speed the labels
will be moving through the readable zone, you can determine the raster sweep rate
by using the formula in
Appendix E — "Formulas for Number of Decodes."
Direction
of travel
Scanner
1-8
MS-850 Raster Scanner User's Manual
Raster
height
