Raster Setup

Format: <KRstatus,top offset,bottom offset,sweep rate,read cycle on/off>
status: top offset:
0 = Disabled Default is 85
1 = Enabled 0 to 255
Example: To enable Raster with a top offset of 5 and a bottom offset of 60, send
<KR1,5,60>.
If raster setup is disabled, the raster mirror will park at the top offset.
If both Read Cycle On/Off and Laser On/Off (see <KC>) are enabled, at the end of a
triggered read cycle, the raster sweep will park at the top offset.
MS-850 Raster Scanner User's Manual
bottom offset: sweep rate:
Default is 170. Default is 10.
.
0 to 255 0 to 30

Raster Setup

read cycle on/off:
0 = Disabled
1 = Enabled
3-23
