Quick Start Overview - Polycom SpectraLink 8020 Administration Manual

Quick Start Overview

1725-36030-001_B.doc
IP multicast addresses are used by the SpectraLink 8030 Wireless
Telephone. This requires that multicasting be enabled on the
subnet used for the SpectraLink 8020/8030 Wireless Telephones,
SVP Server, and Telephony Gateways.
Routers are typically configured with filters to prevent multicast
traffic from flowing outside of specific domains. The wireless LAN
can be placed on a separate virtual LAN (VLAN) or subnet to
reduce the effects of broadcast and multicast traffic from devices in
other network segments.
1. A wireless LAN must be properly configured and operational
through the use of 802.11 wireless APs.
2. A SpectraLink 8000 Telephony Gateway must be available on the
network and the handset must be registered to it in order to load
the appropriate software into the handsets. A separate network
TFTP server is required to distribute software to the handsets.
3. The SpectraLink 8000 Telephony Gateway and SpectraLink 8000
SVP Server must be on the same subnet as the handsets and have
the proper versions of software.
a Download updates to the SpectraLink 8000 SVP Server
software (if the SpectraLink 8000 SVP Server is installed) per
SpectraLink 8000 SVP Server: Administration Guide Chapter 5
Software Updates.
b Download updates to the SpectraLink 8000 Telephony
Gateway software per SpectraLink 8000 Telephony Gateway
Administration Guide Chapter 19 Software Maintenance.
4. Configure the SVP Server per SpectraLink 8000 SVP Server
Administration Guide/
5. Configure the SpectraLink Telephony Gateway per SpectraLink
8000 Telephony Gateway: Administration Guide.
6. Download the correct SpectraLink 8020/8030 Wireless Telephone
software per Chapter 3, section Configuration Process. Ensure the
software is properly loaded on the network TFTP server.
7. Configure your handset to ensure that it associates with the
wireless LAN, has the appropriate software and is registered to
SpectraLink 8000 Wireless Telephone Overview
11
