(2)Power Box
This unit consists of 40XRAY Board, 50Power Supply and its outer cover.
The function; the signal transition between Imaging unit and Control PC, the interface to the
X-ray generator equipment and power supply to the Imaging unit has been implemented.
Item
Communication
interface standard
Communication method
Power supply
Mass
Dimension
(3) Environment rated parameters
Item
Operating temperature
Operating humidity
Keeping or
Transporting
*
IEEE: Institute of Electrical and Electronic Engineers
1. General
Content
*
IEEEE 802.3u (100BASE-TX)
Asynchronous serial communication
method
AC 100-120V±10% 50/60Hz 1.5A
AC 200-240V±10% 50/60Hz 0.8A
4.2 Kg
358(W) x 200(D) x 65(H)* mm
Content
+5 to +35°C
30 to 75% RH
Temperature: -30 to +50°C
Humidity: 10 to 60% RH
Atmospheric pressure: 700 to 1060 hPa
7
Remarks
Connector type: RJ45
Data length: 10bit
Data rate: 15.625 kHz
Reference
CXDI-50G Power supply
Rated Voltage:
AC 100-120V (AC 85-132V)
AC 200-240V (AC170-264V)
Except bottom rubber parts
(With bottom rubber parts:
75mm)
Remarks
Must be without dewing
