xConfiguration SIP Profile [1..1] Line
When registered to a Cisco Unified Communications Manager (CUCM) the endpoint may be part
of a shared line. This means that several devices share the same directory number. The different
devices sharing the same number receive status from the other appearances on the line as defined
in RFC 4235.
Note that shared lines are set up by CUCM, not by the endpoint. Therefore do not change this
setting manually; CUCM pushes this information to the endpoint when required.
Requires user role: ADMIN
Value space: <Private/Shared>
Shared: The system is part of a shared line and is therefore sharing its directory number with other
devices.
Private: This system is not part of a shared line (default).
Example: xConfiguration SIP Profile 1 Line: Private
xConfiguration SIP ListenPort
Turn on or off the listening for incoming connections on the SIP TCP/UDP ports. If turned off, the
endpoint will only be reachable through the SIP registrar (CUCM or VCS). It is recommended to
leave this setting at its default value.
Requires user role: ADMIN
Value space: <On/Off>
On: Listening for incoming connections on the SIP TCP/UDP ports is turned on.
Off: Listening for incoming connections on the SIP TCP/UDP ports is turned off.
Example: xConfiguration SIP ListenPort: On
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration xConfiguration
Standby configuration
xConfiguration Standby Control
xConfiguration Standby Delay
xConfiguration Standby BootAction
57
xCommand
Determine whether the system should go into standby mode or not.
Requires user role: ADMIN
Value space: <Off/On>
Off: The system will not enter standby mode.
On: Enter standby mode when the Standby Delay has timed out. NOTE: Requires the Standby
Delay to be set to an appropriate value.
Example: xConfiguration Standby Control: On
Define how long (in minutes) the system shall be in idle mode before it goes into standby mode.
NOTE: Requires the Standby Control to be enabled.
Requires user role: ADMIN
Value space: <1..480>
Range: Select a value from 1 to 480 minutes.
Example: xConfiguration Standby Delay: 10
Define the camera position after a restart of the codec.
Requires user role: ADMIN
Value space: <None/Preset1/Preset2/Preset3/Preset4/Preset5/Preset6/Preset7/Preset8/
Preset9/Preset10/Preset11/Preset12/Preset13/Preset14/Preset15/RestoreCameraPosition/
DefaultCameraPosition>
None: No action.
Preset1 to Preset15: After a reboot the camera position will be set to the position defined by the
selected preset.
RestoreCameraPosition: After a reboot the camera position will be set to the position it had before
the last boot.
DefaultCameraPosition: After a reboot the camera position will be set to the factory default
position.
Example: xConfiguration Standby BootAction: DefaultCameraPosition
