xConfiguration Video Layout LocalLayoutFamily
Select which video layout family to use locally.
Requires user role: ADMIN
Value space: <Auto/FullScreen/Equal/PresentationSmallSpeaker/PresentationLargeSpeaker/
Prominent/Overlay/Single>
Auto: The default layout family, as given in the layout database provided by the system, will be
used as the local layout.
FullScreen: The FullScreen layout family will be used as the local layout. It means that the active
speaker or presentation will be shown in full screen. Using this value is not recommended as from
TC6.0.
Equal: The Equal layout family will be used as the local layout. All videos have equal size, as long
as there is space enough on the screen.
PresentationSmallSpeaker: The PresentationSmallSpeaker layout family will be used as the local
layout. Using this value is not recommended as from TC6.0.
PresentationLargeSpeaker: The PresentationLargeSpeaker layout family will be used as the local
layout. Using this value is not recommended as from TC6.0.
Prominent: The Prominent layout family will be used as the local layout. The active speaker, or the
presentation if present, will be a large picture, while the other participants will be small pictures.
Transitions between active speakers are voice switched.
Overlay: The Overlay layout family will be used as the local layout. The active speaker, or the
presentation if present, will be shown in full screen, while the other participants will be small
pictures-in-picture (PiP). Transitions between active speakers are voice switched.
Single: The active speaker, or the presentation if present, will be shown in full screen. The other
participants are not shown. Transitions between active speakers are voice switched.
Example: xConfiguration Video Layout LocalLayoutFamily: Auto
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration xConfiguration
xConfiguration Video Layout RemoteLayoutFamily
xConfiguration Video Monitors
68
xCommand
Select which video layout family to be used for the remote participants.
Requires user role: ADMIN
Value space: <Auto/FullScreen/Equal/PresentationSmallSpeaker/PresentationLargeSpeaker/
Prominent/Overlay/Single>
Auto: The default layout family, as given by the local layout database, will be used as the remote
layout.
FullScreen: The FullScreen layout family will be used as the remote layout. It means that the active
speaker or presentation will be shown in full screen. It is recommended not to use this value as
from TC6.0.
Equal: The Equal layout family will be used as the remote layout. All videos have equal size, as long
as there is space enough on the screen.
PresentationSmallSpeaker: The PresentationSmallSpeaker layout family will be used as the remote
layout. Using this value is not recommended as from TC6.0.
PresentationLargeSpeaker: The PresentationLargeSpeaker layout family will be used as the
remote layout. Using this value is not recommended as from TC6.0.
Prominent: The Prominent layout family will be used as the remote layout. The active speaker,
or the presentation if present, will be a large picture, while the other participants will be small
pictures. Transitions between active speakers are voice switched.
Overlay: The Overlay layout family will be used as the remote layout. The active speaker, or the
presentation if present, will be shown in full screen, while the other participants will be small
pictures-in-picture (PiP). Transitions between active speakers are voice switched.
Single: The active speaker, or the presentation if present, will be shown in full screen. The other
participants are not shown. Transitions between active speakers are voice switched.
Example: xConfiguration Video Layout RemoteLayoutFamily: Auto
Set the monitor layout mode.
Requires user role: ADMIN
Value space: <Single/Dual/DualPresentationOnly>
Single: The same layout is shown on all monitors.
Dual: The layout is distributed on two monitors.
DualPresentationOnly: All participants in the call will be shown on the first monitor, while the
presentation (if any) will be shown on the second monitor.
Example: xConfiguration Video Monitors: Single
