Cisco TelePresence SX20 Codec
Contents Introduction

xStatus Network 1 IPv4 DHCP ProvisioningDomain

Returns the SIP domain of the VCS provisioning server as assigned by DHCP, provided the
provisioning server address is defined as a vendor encapsulated option in the DHCP server. This
status is used only when xConfiguration Provisioning Mode is VCS.
Value space of the result returned:
<String>
Example:
xStatus Network 1 IPv4 DHCP ProvisioningDomain
*s Network 1 IPv4 DHCP ProvisioningDomain: "1234@company.com"
** end

xStatus Network 1 IPv4 DHCP TftpServer

Returns the IP address or DNS name of the TFTP server (provisioning server) as assigned by
DHCP, provided the DHCP server sets the option 66. This status is used only when xConfiguration
Provisioning Mode is CUCM.
Value space of the result returned:
<String>
Example:
xStatus Network IPv4 DHCP TftpServer
*s Network 1 IPv4 DHCP TftpServerAddress: "192.0.2.0"
*s Network 1 IPv4 DHCP TftpServer: "1234@company.com"
** end

xStatus Network 1 IPv6 Address

Shows the IPv6 address that uniquely identifies this system.
Value space of the result returned:
<String>
Example:
xStatus Network 1 IPv6 Address
*s Network 1 IPv6 Address: ""
** end
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration

xStatus Network 1 IPv6 Gateway

xStatus Network 1 MTU

xStatus Network 1 VLAN Voice VlanId

xStatus Network VLAN Native VlanId

151
xCommand
Shows the address of the IPv6 gateway.
Value space of the result returned:
<String>
Example:
xStatus Network 1 IPv6 Gateway
*s Network 1 IPv6 Gateway: ""
** end
Shows the MTU (Maximum Transmission Unit) size for the network.
Value space of the result returned:
<Integer>
Example:
xStatus Network 1 MTU
*s Network 1 MTU: 1500
** end
The feedback shows the VLAN Voice ID; or Off if the VLAN Voice Mode is not enabled.
Value space of the result returned:
<"Off"/"1".."4094">
Example:
xStatus Network 1 VLAN Voice VlanId
*s Network 1 VLAN Voice VlanId: "Off"
** end
Identifies the VLAN associated with any untagged traffic between the switch and the endpoint. For
more information see documentation for the IEEE 802.1Q protocol.
Value space of the result returned:
<String>
Example:
xStatus Network VLAN Native VlanId
*s Network 1 VLAN Native VlanId: "200"
** end
API Reference Guide
xStatus xStatus Appendices
