Cisco TelePresence SX20 Codec
Contents Introduction
xStatus Video Layout Site [1..n] Output [1..2] GraphicName
Shows the name of the graphic layout. The name identifies the layout used right now at the
specified output.
NOTE: Note that while the FamilyName is constant as the long as the configurations on the system
does not change, the GraphicName varies depending on system state (the number of participants
for instance).
Value space of the result returned:
<String>
Example:
xStatus Video Layout Site 1 Output 1 GraphicName
*s Video Layout Site 1 Output 1 GraphicName: "full-pip"
** end
xStatus Video Layout Site [1..n] Output [1..2] Frame [1..6] PositionX
Shows the horizontal position of the upper left corner of the frame.
Value space of the result returned:
<0..10000>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 PositionX
*s Video Layout Site 1 Output 1 Frame 1 PositionX: 0
** end
xStatus Video Layout Site [1..n] Output [1..2] Frame [1..6] PositionY
Shows the vertical position of the upper left corner of the frame.
Value space of the result returned:
<0..10000>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 PositionY
*s Video Layout Site 1 Output 1 Frame 1 PositionY: 0
** end
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration
xStatus Video Layout Site [1..n] Output [1..2] Frame [1..6] Width
xStatus Video Layout Site [1..n] Output [1..2] Frame [1..6] Height
xStatus Video Layout Site [1..n] Output [1..2] Frame [1..6] Layer
xStatus Video Layout Site [1..n] Output [1..2] Frame [1..6] VideoSourceType
174
xCommand
Shows the width of the frame.
Value space of the result returned:
<0..10000>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 Width
*s Video Layout Site 1 Output 1 Frame 1 Width: 10000
** end
Shows the height of the frame.
Value space of the result returned:
<0..10000>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 Height
*s Video Layout Site 1 Output 1 Frame 1 Height: 10000
** end
Shows the layer of the frame.
Value space of the result returned:
<1..6>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 Layer
*s Video Layout Site 1 Output 1 Frame 1 Layer: 1
** end
Describes the video source type in the frame.
Value space of the result returned:
<String>
Example:
xStatus Video Layout Site 1 Output 1 Frame 1 VideoSourceType
*s Video Layout Site 1 Output 1 Frame 1 VideoSourceType: "graphic"
** end
API Reference Guide
xStatus xStatus Appendices
Copyright © 2013 Cisco Systems, Inc. All rights reserved.
