xCommand SystemUnit ReleaseKey List
List all software versions that the system has a valid release key for.
Requires user role: ADMIN
Example:
xCommand SystemUnit ReleaseKey List
*r SystemUnit ReleaseKey 1 Version: "TC1"
*r SystemUnit ReleaseKey 2 Version: "TC2"
*r SystemUnit ReleaseKey 3 Version: "TC3"
*r SystemUnit ReleaseKey 4 Version: "TC4"
*r SystemUnit ReleaseKey 5 Version: "TC5"
** end
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration

Video commands

xCommand Video PictureLayoutSet
xCommand Video Layout SetPresentationView
109
xCommand xCommand
Select the screen layout mode.
Target: Select if the target is the local layout or the remote layout.
CallId: The CallID is returned when the xCommand Dial command is run. During the call you can run
the xStatus Call command to see the CallId.
LayoutFamily: Select a layout family.
CustomLayoutName: Enter a name for the layout.
Requires user role: USER
Parameters:
Target: <local/remote>
CallId: <0..65534>
LayoutFamily(r): <auto/custom/equal/fullscreen/overlay/presentationlargespeaker/
presentationsmallspeaker/prominent/single/speaker_full>
CustomLayoutName: <S: 1, 128>
Example:
xCommand Video PictureLayoutSet Target: Local LayoutFamily: equal
*r SetPictureLayoutResult (status=OK):
** end
Set the presentation view mode.
View: Select Default when you want the presentation to be viewed with the default settings for the
codec. Select Maximized when you want the presentation to be displayed in full screen. Select
Minimized when you want the presentation to be displayed in a small picture on screen.
Requires user role: ADMIN
Parameters:
View(r): <Default/Maximized/Minimized>
Example:
xCommand Video Layout SetPresentationView View:Default
OK
*r VideoLayoutSetPresentationViewResult (status=OK):
** end
