FLIR LOREX LNB4321 Series Quick Start Manual

Contents
• IR Bullet IP Camera*
• Mounting Kit*
• Mounting Template*
• Cat5e UL Compliant (CM) Ethernet Extension Cable*
* Per camera.
ATTENTION - It is recommended to connect the camera to the
NVR or an external PoE switch. If using a DC power adapter with
the camera, a REGULATED power supply is REQUIRED for use
with this camera. Use of a non-regulated, non-conforming power
supply can damage this product and voids the warranty.
Warning/Caution
• Use the camera only with compatible Lorex NVRs
• Read this guide carefully and keep it for future reference
• Follow all instructions for safe use of the product and handle with care
• Do not disassemble the camera
• Do not point the camera directly towards the sun or a source of intense light
• Periodic cleaning may be required. Use a damp cloth only. Do not use harsh cleaners or
aerosol cleaners
• The supplied cable is rated for in-wall and surface mounting. Cables for floor-to-floor
installations are sold separately (CMR type). These and other cables are available at
www.lorextechnology.com
Installation Tips
• Point the camera where there is the least amount of obstructions (i.e. tree branches)
• Install the camera in a location that is difficult for vandals to reach
• Secure cabling so that it is not exposed or easily cut
• Camera rated for outdoor use. Installation in a sheltered location recommended
LNB4321_SERIES_TRIFOLDQSG_EN_R1
Dimensions
75mm / 3.0"
72mm / 2.8"
172mm / 6.7"
Resources
Need Help?
Visit us online for up-to-date
software and complete instruction manuals
1
Go to www.lorextechnology.com
2
Search the model number of your product
3
Click on your product in the search results
4
Click on the Downloads tab
The following resources are always at your fingertips
Product Information Specification Sheets
User Manuals Software Upgrades
Quick Start Guides Firmware Upgrades
© 2016 Lorex Corporation
As our product is subject to continuous improvement, Lorex Corporation & subsidiaries reserve the right to
modify product design, specifications & prices without notice and without incurring any obligation. E&OE
4 MP HD IR BULLET IP CAMERA
Quick Start Guide
English Version 1.0
.
LNB4321 Series
