FLIR P143E4 SERIES Quick Start Manual

Compatible Accessories
This security camera has several mounting options:
Accessories Model Numbers
Junction Boxes S1JF2G or S4JF1G
Wall Mount S1WA1G
Pole Mounts S4PA2G with S1WA1G, or
S4PA2G with S1JF2G
Safety Precautions
• Use an appropriate low-voltage power cable to
prevent fire or electrical shock.
• Make sure to install the camera in an area that can
support the camera weight.
• There are no user-serviceable parts inside the
camera. Please do not disassemble the camera.
• Do not clean the lens cover with an abrasive
cleaning materials. Please use a soft cloth to clean
the lens cover.
• Camera is rated for outdoor use (IP66), but is not
intended for submersion in water.
• Extend the Ethernet-cable run for your camera
up to 300ft. You can use an RJ45 coupler or
network switch to connect male ends of Ethernet
cable together. A maximum of 3 connections is
recommended.
Weights & Dimensions
3.7" / 93mm
Weight
0.7lbs / 0.35kg
3.2"
80mm
Using the RJ45 Cap (Optional)
Outer seal
Cap housing
Ethernet RJ45 plug Inner
connector seal
Fit the outer seal over your camera's Ethernet connector
1
and insert the inner seal into the cap housing.
2 Run the stripped end of an Ethernet cable through the
parts of the RJ45 cap, as shown above.
3 Terminate the Ethernet cable with an RJ45 plug, and plug
the cable into your camera's Ethernet connector.
4
Screw the cap housing onto the Ethernet connector.
5 Screw the cap-sealing nut tightly into the cap
housing.
ATTENTION:
The supplied RJ45 cap is weather-resistant. Seal the cap with
silicone if it will be exposed to precipitation regularly.
FCC Notice
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
IT'S ALL ON THE WEB!
VISIT
flir.com/security/pro
FLIR Systems, Inc., Copyright © 2017
As our products are subject to continuous improvement, FLIR Systems
Inc. reserves the right to modify product design, specifications and
prices, without notice and without incurring any obligation. E&OE
P143E4_QSG_EN_R1
Cap-sealing nut
QUICK START GUIDE
English Version 1.0
4MP HD IP
Eyeball Dome Camera
MODEL:
P143E4 SERIES
flir.com/security/pro
