110 Appendix D: Tower and Drive Installation
Connecting the
SCSI Drives
To connect the SCSI drives to the StorPoint NAS, follow these steps:
1. Connect the SCSI cable to the SCSI connector on the StorPoint
NAS.
2. Connect the SCSI cable to the hard disk(s).
3. Set a unique SCSI address 0 through 15, excluding 7, for each of the
connected hard disks.
❏ The SCSI address of the StorPoint NAS is 7, and cannot be
changed.
4. Connect an external, preferably active, SCSI terminator to the last
drive in the SCSI chain. If there is only one drive, it is the last one in
the chain and must be terminated. The StorPoint NAS has built-in
SCSI termination which is always switched on. Therefore, the server
must be physically located at one end of the chain.
❏ Do not terminate the hard disks placed between the StorPoint NAS
and the last hard disk.
5. Switch the power on to the whole of the tower.
6. The StorPoint NAS front panel indicators will flash during power-on
and self-test. When the Status indicator stops flashing and turns solid
green, the StorPoint NAS is ready for use.
