LEDs

This appendix includes the following topics:
•
•
•
•
•
•

Chassis LEDs

Chassis LEDs
LED
PSU
FAN
SUP
OL-30453-01
Chassis LEDs, page 191
Supervisor Module LEDs, page 192
I/O Module LEDs, page 194
Fabric Module LEDs, page 195
Fan Tray LEDs, page 196
Power Supply LEDs, page 196
Color Status
Green Power supplies are all operational.
Amber One of the following problems exist:
• At least one power supply LED is red.
• At least one power supply is down.
Green Fan trays are all operational.
Amber At least one fan tray module LED is red.
Green Supervisor modules are all operational.
Amber At least one supervisor module LED is red.
