Emerson FIELDVUE DVC6200f Instruction Manual page 97

Label
PARAMETER_NAME
PD Detail 5 Active
PD_DETAIL5_ACTIVE
PD Detail 6 Active
PD_DETAIL6_ACTIVE
Shutdown Alerts
SHUTDOWN_ALERTS_ACTIVE
1. These parameters can be written when PWA_SIMULATE is active and Protect Category is not ALL.
November 2010
Table 4-14. Transducer Block Parameter Definitions (Continued)
Index RO /
Mode Range
Number RW
0: Relay Disengaged
1: Insufficient Pressure
Differential
2: Travel Calibration
Error
3: Reserved
4: High Supply
Pressure*
5: Reserved
6: Near a Travel Cutoff
Or Stop
7:Reserved
(1)
74.13 RO ALL
8: Spec Sheet Fields
Incomplete*
9: Sensor Failure*
10: Pressure Control
Active
11: Transducer Block
Mode OOS
12: Not Authorized for
PD
13: PD Run Disabled*
14: Trigger Data
Available*
(1)
74.14 RO ALL Reserved
0: Drive Current
1: Program Memory
2: Static Memory
3: Processor or I/O
Processor
74.15 RO N/A
4: Travel Sensor
5: Port A Pressure
Sensor
6: Output Block Timeout
7−31: (Reserved)
−Continued−
Transducer Block
Protect
Initial Value
Category
Data Type: Bit String (4 byte)
0=inactive
1=active
Performance Diagnostic Detail
All bits: 0 N/A
status
*Bits which, when set, will trigger
PERF_ACTIVE bit 2.
Data Type: Bit String (4 byte)
0=inactive
1=active
All bits: 0 N/A
Performance Diagnostic Detail
status
Data Type: Bit String (4 byte)
0=inactive
1=active
Indicates what caused an
Instrument Shutdown. Bit remains
set even if condition has passed if
All bits: 0 N/A Shutdown Recovery is Manual. All
bits are cleared when
MODE_BLK.TARGET is written.
Always enabled whenever the
corresponding
SHUTDOWN_TRIGGER is
enabled.
Description
4
85
