View Lists

View lists allow the values of a set of parameters to be
accessed at the same time. Views 1 and 2 contain
operating parameters and are defined by the Fieldbus
Foundation. View 3 contains dynamic parameters and
View 4 contains static parameters with configuration
and maintenance information. Views 3 and 4 are
defined by the manufacturer.
Table 4-58. AI Function Block, View 1
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 OUT
19 FIELD_VAL
22.1 ALARM_SUM.CURRENT
22.2 ALARM_SUM.UNACKNOWLEDGED
22.3 ALARM_SUM.UNREPORTED
22.4 ALARM_SUM.DISABLED
Table 4-59. AI Function Block, View 2
Index
Number
1 ST_REV
10 XD_SCALE
11 OUT_SCALE
12.1 GRANT_DENY.GRANT
12.2 GRANT_DENY.DENY
November 2010
Parameter
Parameter
AI Function Block
Table 4-60. AI Function Block, View 3
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 OUT
19 FIELD_VAL
22.1 ALARM_SUM.CURRENT
22.2 ALARM_SUM.UNACKNOWLEDGED
22.3 ALARM_SUM.UNREPORTED
22.4 ALARM_SUM.DISABLED
37 OUT_D
38 ALM_SEL
39 STDDEV
40 CAP_STDDEV
Table 4-61. AI Function Block, View 4
Index
Number
1 ST_REV
3 STRATEGY
4 ALERT_KEY
13 IO_OPTS
14 STATUS_OPTS
15 CHANNEL
16 L_TYPE
17 LOW_CUT
18 PV_FTIME
23 ACK_OPTION
24 ALARM_HYS
25 HI_HI_PRI
26 HI_HI_LIM
27 HI_PRI
28 HI_LIM
29 LO_PRI
30 LO_LIM
31 LO_LO_PRI
32 LO_LO_LIM
Parameter
Parameter
