View Lists

View lists allow the values of a set of parameters to be
accessed at the same time. Views 1 and 2 contain
operating parameters and are defined by the Fieldbus
Foundation. View 3 contains dynamic parameters and
View 4 contains static parameters with configuration
and maintenance information. Views 3 and 4 are
defined by the manufacturer.
Table 4-49. OS Function Block, View 1
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 SP
8 OUT_1
9 OUT_2
14 CAS_IN
Table 4-50. OS Function Block, View 2
Index
Number
1 ST_REV
10 OUT_1_RANGE
11 OUT_2_RANGE
12.1 GRANT_DENY.GRANT
12.2 GRANT_DENY.DENY
November 2010
Parameter
Parameter
OS Function Block
Table 4-51. OS Function Block, View 3
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 SP
8 OUT_1
9 OUT_2
14 CAS_IN
15 BKCAL_OUT
19 BKCAL_1_IN
20 BKCAL_2_IN
Table 4-52. OS Function Block, View 4
Index
Number
1 ST_REV
3 STRATEGY
4 ALERT_KEY
13 STATUS_OPTS
16 IN_ARRAY
17 OUT_ARRAY
18 LOCKVAL
21 BAL_TIME
Parameter
Parameter
