Emerson FIELDVUE DVC6200f Instruction Manual page 140

DVC6200f Digital Valve Controller
Note
Because individual views are limited in
size, View List 4 has two parts.
Table 4-36. PID Function Block, View 4.1
Index
Number
1 ST_REV
3 STRATEGY
4 ALERT_KEY
4
13 CONTROL_OPTS
14 STATUS_OPTS
16 PV_FTIME
19 SP_RATE_DN
20 SP_RATE_UP
23 GAIN
24 RESET
25 BAL_TIME
26 RATE
30 BKCAL_HYS
34 SHED_OPT
37 TRK_SCALE
41 FF_SCALE
42 FF_GAIN
46 ACK_OPTION
47 ALARM_HYS
48 HI_HI_PRI
49 HI_HI_LIM
50 HI_PRI
51 HI_LIM
52 LO_PRI
53 LO_LIM
54 LO_LO_PRI
55 LO_LO_LIM
56 DV_HI_PRI
57 DV_HI_LIM
58 DV_LO_PRI
59 DV_LO_LIM
128
Parameter
Table 4-37. PID Function Block, View 4.2
Index
Number
1 ST_REV
66 BIAS
69 SP_FTIME
70 MATHFORM
71 STRUCTURECONFIG
72 GAMMA (ugamma)
73 BETA
74 IDEADBAND
Parameter
November 2010
