Emerson FIELDVUE DVC6200f Instruction Manual page 244

DVC6200f Digital Valve Controller
Parts Ordering
Whenever corresponding with your Emerson Process
Management sales office about this equipment,
always mention the controller serial number. When
ordering replacement parts, refer to the 11-character
part number of each required part as found in the
following parts list. Part numbers are shown for kits
and recommended spares only. For part numbers not
shown, contact your Emerson Process Management
sales office.
Use only genuine Fisher replacement
parts. Components that are not
supplied by Emerson Process
Management should not, under any
circumstances, be used in any Fisher
instrument. Use of components not
supplied by Emerson Process
Management may void your warranty,
might adversely affect the
performance of the instrument, and
8
could cause personal injury and
property damage.
Note
Neither Emerson, Emerson Process
Management, nor any of their affiliated
entities assumes responsibility for the
selection, use, and maintenance of any
product. Responsibility for the
selection, use, and maintenance of any
product remains with the purchaser
and end user.
232
WARNING
Parts Kits
Kit Description
1* Elastomer Spare Parts Kit (kit contains parts to
service one digital valve controller)
Standard
Extreme Temperature option
(fluorosilicone elastomers)
2* Small Hardware Spare Parts Kit (kit contains parts
to service one digital valve controller)
3* Seal Screen Kit
[kit contains 25 seal screens (key 231)
and 25 O-rings (key 39)]
Standard and Extreme Temperature option
(fluorosilicone elastomers)
4* Terminal Box Kit, aluminum
Standard
Standard, Natural Gas approved
Extreme Temperature option (fluorosilicone
elastomers)
Extreme Temperature option (fluorosilicone
elastomers) Natural Gas Approved
5* I/P Converter Kit
Standard
For Extreme Temperature option
(fluorosilicone elastomers)
6* Spare Module Base Assembly Kit, aluminum
[kit contains module base (key 2); drive screws, qty. 2,
(key 11); shield/label (key 19); hex socket cap screw, qty. 3,
(key 38); self tapping screw, qty. 2 (key 49); pipe plug, qty. 3
(key 61); retaining ring, qty. 3 (key 154); screen (key 236);
and flame arrestors, qty. 3 (key 243)]
7* Spare Housing Assembly Kit, aluminum
[kit contains housing (key 1); vent assembly (key 52);
seal (only included in Housing A kits) (key 288);
seal (key 237); O-ring (key 34); O-ring (only used
with integrally mounted regulator) (key 5)]
Housing A (used for GX actuator)
Standard (nitrile elastomers)
Extreme Temperature option
(fluorosilicone elastomers)
Housing B (used for all actuators except GX)
Standard (nitrile elastomers)
Extreme Temperature option
(fluorosilicone elastomers)
8* Spare I/P Shroud Kit
[kit contains shroud (key 169) and
hex socket cap screw, qty. 4 (key 23)]
*Recommended spare
Part Number
19B5402X012
19B5402X022
19B5403X012
14B5072X182
GE44077X012
GE44081X012
GE44078X012
GE44082X012
38B6041X152
38B6041X132
GE18654X012
GE48798X012
GE48798X022
GE48798X052
GE48798X062
GE29183X012
November 2010
