DVC6200f Digital Valve Controller

View Lists

View lists allow the values of a set of parameters to be
accessed at the same time. Views 1 and 2 contain
operating parameters and are defined by the Fieldbus
Foundation. View 3 contains dynamic parameters and
View 4 contains static parameters with configuration
and maintenance information. Views 3 and 4 are
defined by the manufacturer.
Table 4-26. AO Function Block, View 1
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
4
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 SP
9 OUT
16 READBACK
17 CAS_IN
Table 4-27. AO Function Block, View 2
Index
Number
1 ST_REV
11 PV_SCALE
12 XD_SCALE
13.1 GRANT_DENY.GRANT
13.2 GRANT_DENY.DENY
20 SP_HI_LIM
21 SP_LO_LIM
108
Parameter
Parameter
Table 4-28. AO Function Block, View 3
Index
Number
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 SP
9 OUT
16 READBACK
17 CAS_IN
25 BKCAL_OUT
26 RCAS_IN
28 RCAS_OUT
31 STDDEV
32 CAP_STDDEV
Table 4-29. AO Function Block, View 4
Index
Number
1 ST_REV
3 STRATEGY
4 ALERT_KEY
14 IO_OPTS
15 STATUS_OPTS
18 SP_RATE_DN
19 SP_RATE_UP
22 CHANNEL
23 FSTATE_TIME
24 FSTATE_VAL
27 SHED_OPT
Parameter
Parameter
