Specifications
Control card performance
Scan interval
Control card, USB serial communication
USB standard
USB plug
Generic specifications
Maximum parallel filters
Filter efficiency
Typical average switching frequency
Response time (reactive and harmonic)
Settling time - reactive current control
Settling time - harmonic current control
Overshoot – reactive current control
Overshoot – Harmonic current control
WARNING
Connection to PC is carried out via a standard host/device USB cable. The USB connection is galvanically isolated from
the supply voltage (PELV) and other high-voltage terminals. The USB connection is not galvanically isolated from
protective earth. Use only isolated laptop/PC as connection to the USB connector on the unit or an isolated USB cable/
converter.
Protection and features
•
Temperature monitoring of the heat sink ensures that the active filter trips if the temperature reaches a predefined
level. An overload temperature cannot be reset until the temperature of the heat sink is below the acceptable
values.
•
If a mains phase is missing, the active filter trips.
•
The active filter has a short circuit protection current rate of 100 kA if properly fused
•
Monitoring of the DC-link voltage ensures that the filter trips if the DC-link voltage is too low or too high.
•
The active filter monitors the mains current as well as internal currents to reassure that current levels do not reach
critical levels. If current exceeds a critical level, the filter trips.
Rated Current
Losses
Needed Airflow
Frame
Nominal
Nominal
Maximum individual hamonic
compensation in back channel
Nominal/(maximum)
Table 9.1
Note: Numbers are rounded to nearest amp
MG90V302
Operating Instructions
Current [A]
Watt [kW]
3
M /h
Reactive [A]
Harmonic [A]
I
5
I
7
I
11
I
[A]
13
I
17
I
19
I
23
I
25
Danfoss A/S © 09/2014 All rights reserved.
USB type B "device" plug
190 250
5 7
765 1230
D E
190 250
170 225
119 158
85 113
54 72
48 63
34 45
31 41
27 36
24 32
5 ms
1.1 (full speed)
4 on same CT set
97%
3.0–4.5 kHz
<0.5 ms
<20 ms
<20 ms
<10%
<10%
310 400
9 11
1230 1230
E F
310 400
280 360
196 252
140 180
90 115
78 101
56 72
50 65
45 58
39 50
83
9 9
