8.3 Active Filter Warning and Alarm Definitions

NOTICE
After a manual reset pressing [Reset], press [Auto On] or [Hand On] to restart the unit.
If an alarm cannot be reset, the reason may be that its cause has not been rectified, or the alarm is trip-locked (see also
Table 8.1).
Alarms that are trip-locked offer additional protection, meaning that the mains supply must be switched off before the
alarm can be reset. After being switched back on, the unit is no longer blocked and may be reset as described in
chapter 8.2.2 Alarm Trip once the cause has been rectified.
Alarms that are not trip-locked can also be reset using the automatic reset function in 14-20 Reset Mode. Automatic wake-up
is possible during this type of reset.
If a warning and alarm is marked against a code in Table 8.1, either a warning occurs before an alarm, or the display for a
given fault (warning or alarm) is configurable.
Number Description
1 10 Volts low
8 8
2 Live zero error
4 Mains phase loss
5 DC link voltage high
6 DC link voltage low
7 DC over voltage
8 DC under voltage
13 Over current
14 Earth fault
15 Hardware mismatch
16 Short circuit
17 Control word timeout
23 Internal fan fault
24 External fan fault
29 Heatsink temp
33 Inrush fault
34 Fieldbus fault
35 Option fault
38 Internal fault
39 Heatsink sensor
40 Overload of digital output terminal 27
41 Overload of digital output terminal 29
46 Pwr. card supply
47 24 V supply low
48 1.8 V supply low
65 Control board over-temperature
66 Heat sink temperature low
67 Option configuration has changed
68 Safe torque off activated
69 Pwr. card temp
70 Illegal FC configuration
72 Dangerous failure
73 Safe torque off auto restart
76 Power unit setup
76
Operating Instructions
Warning Alarm/Trip
X
(X)
X
X
X
X
X
X
X
(X)
X
X
X
X
X
(X)
(X)
X
X
X
X
