8-06 Reset Control Word Timeout
This parameter is active only when [0] Hold set-up has been
selected in parameter 8-05 End-of-Timeout Function.
Option:
Function:
performs the reset and then immediately
reverts to the [0] Do not reset setting
6.6.2 8-3* FC Port Settings
8-30 Protocol
Option:
Function:
[0]
FC
Communication according to the FC Protocol.
*
[1]
FC MC
Select the protocol for the FC (standard) port.
[2]
Modbus RTU
8-31 Address
Range:
Function:
Size related
[ 1 - 255 ] Enter the address for the FC (standard)
*
port.
Valid range: 1-126.
8-32 FC Port Baud Rate
Option:
Function:
[0] 2400 Baud
Baud rate selection for the FC (standard) port.
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-35 Minimum Response Delay
Range:
Function:
10 ms
[ 1 - 10000
Specify the minimum delay time
*
ms]
between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
8-36 Max Response Delay
Range:
Function:
Size
[ 11 -
Specify the maximum permissible
related
10001 ms]
delay time between transmitting a
*
request and receiving a response. If a
response from the frequency converter
is exceeding the time setting, then it is
discarded.
8-37 Max Inter-Char Delay
Range:
Function:
Size
[ 0.00 -
Specify the maximum permissible time
related
35.00 ms]
interval between receipt of 2 bytes. This
*
MG90V302
Operating Instructions
8-37 Max Inter-Char Delay
Range:
8-53 Start Select
Option:
[0]
Digital
input
[1]
Bus
[2]
Logic
AND
[3]
Logic
OR
*
8-55 Set-up Select
Option:
[0]
Digital
input
[1]
Bus
[2]
Logic
AND
[3]
Logic
*
OR
Danfoss A/S © 09/2014 All rights reserved.
Function:
parameter activates timeout if
transmission is interrupted.
This parameter is active only when
parameter 8-30 Protocol is set to [1] FC MC
protocol.
Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the unit start function via the
terminals (digital input) and/or via the fieldbus.
Activates a start command via a digital input.
Activates a start command via the serial
communication port or Fieldbus option.
Activates a start command via the fieldbus/serial
communication port, AND additionally via one of
the digital inputs.
Activates a start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the unit set-up selection via the
terminals (digital input) and/or via the fieldbus.
Activates the set-up selection via a digital input.
Activates the set-up selection via the serial
communication port or fieldbus option.
Activates the set-up selection via the fieldbus/
serial communication port, AND additionally via
one of the digital inputs.
Activate the set-up selection via the fieldbus/
serial communication port OR via one of the
digital inputs.
6
6
49
