0-20 Display Line 1.1 Small
Option:
[30100] Output Current [A]
[30101] Output Current [%]
[30102] Fifth Output Current
[A]
[30103] Seventh Output
Current [A]
[30104] Eleventh Output
Current [A]
[30105] Thirteenth Output
Current [A]
[30106] Seventeenth Output
Current [A]
6 6
[30107] Nineteenth Output
Current [A]
[30108] Twenty-third Output
Current [A]
[30109] Twenty-fifth Output
Current [A]
[30110] THD of current [%]
[30112] Power factor
[30113] Cosphi
[30114] Leftover Currents
[30120] Mains Current [A]
[30121] Mains Frequency
[30122] Fund. Mains Current
[A]
0-21 Display Line 1.2 Small
Option: Function:
[0] None Select a variable for display in line 1, middle
*
position. The options are the same as those listed for
0-20 Display Line 1.1 Small.
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position. The options
are the same as those listed for 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Select a variable for display in line 2. The options are the same
as listed for 0-20 Display Line 1.1 Small. The options are the same
as those listed in 0-20 Display Line 1.1 Small.
0-24 Display Line 3 Large
Select a variable for display in line 3.
0-25 My Personal Menu
Range:
Size [0 -
related 9999]
*
44
Operating Instructions
Function:
Function:
Define up to 50 parameters to appear in the
Q1 Personal Menu, accessible via the [Quick
Menu] key on the LCP. The parameters are
displayed in the Q1 Personal Menu in the
order they are programmed into this array
parameter. Delete parameters by setting the
value to '0000'.
Danfoss A/S © 09/2014 All rights reserved.
0-25 My Personal Menu
Range: Function:
For example, this can be used to provide
quick, simple access to just 1 or up to 50
parameters which require changing on a
regular basis (e.g. for plant maintenance
reasons) or by an OEM to enable simple
commissioning of their equipment.
6.4.4 0-4* LCP Keypad
Enable, disable and password protect individual keys on
the LCP.
0-40 [Hand on] Key on LCP
Option: Function:
[0] Disabled No effect when [Hand on] is pressed. Select [0]
Disabled to avoid accidental start of the
frequency converter in Hand on mode.
[1] Enabled
*
[2] Password Avoids unauthorised stop. If parameter 0-41 [Off]
Key on LCP is included in the Quick Menu, then
define the password in parameter 0-65 Quick
Menu Password.
0-41 [Off] Key on LCP
Option: Function:
[0] Disabled Avoids accidental stop of the unit.
[1] Enabled
[2] Password Avoids unauthorised stop. If parameter 0-41 [Off]
Key on LCP is included in the Quick Menu, then
define the password in parameter 0-65 Quick Menu
Password.
0-42 [Auto on] Key on LCP
Option: Function:
[0] Disabled Avoid accidental start of the unit in Auto mode.
[1] Enabled
[2] Password Avoids unauthorised start in Auto On mode. If
parameter 0-42 [Auto on] Key on LCP is included in
the Quick Menu, then define the password in
parameter 0-65 Quick Menu Password.
0-43 [Reset] Key on LCP
Option: Function:
[0] Disabled No effect when [Reset] is pressed. Avoids
accidental alarm reset.
[1] Enabled
[2] Password Avoids unauthorised resetting. If
parameter 0-43 [Reset] Key on LCP is
included in the Quick Menu, then define
the password in parameter 0-65 Quick Menu
Password.
