Electrical Installation

4.3 Installation Checklist

Before completing installation of the unit, inspect the entire installation as detailed in Table 4.14. Check and mark the items
when completed.
Inspect for
Description
Auxiliary equipment
Ensure that all auxiliary equipment, such as switches, disconnects, or input fuses/circuit breakers are ready
for operation.
Check function and installation of any sensors used for feedback to the active filter.
Cable routing
Ensure that power wiring and control wiring are separated, screened, or in 3 separate metallic conduits for
high-frequency interference isolation.
Control wiring
Check for broken or damaged wires and loose connections.
Check that control wiring is isolated from power wiring for noise immunity.
Check the voltage source of the signals, if necessary.
The use of shielded cable or twisted pair is recommended. Ensure that the shield is terminated correctly.
Cooling clearance
Measure that top and bottom clearance is adequate to ensure proper air flow for cooling, see
chapter 3.2.4 Cooling and Airflow .
Ambient conditions
Check that requirements for ambient conditions are met.
Fusing and circuit
Check for proper fusing or circuit breakers.
breakers
Check that all fuses are inserted firmly and are in operational condition and that all circuit breakers are in
the open position.
Grounding
Check for good ground connections that are tight and free of oxidation.
Grounding to conduit, or mounting the back panel to a metal surface, is not a suitable grounding.
Input and output
Check for loose connections.
power wiring
Check that motor and mains are in separate conduit or separated screened cables.
Panel interior
Inspect that the unit interior is free of dirt, metal chips, moisture, and corrosion.
Check that the unit is mounted on an unpainted, metal surface.
Switches
Ensure that all switch and disconnect settings are in the proper positions.
Vibration
Check that the unit is mounted solidly, or that shock mounts are used, as necessary.
Check for an unusual amount of vibration.
Table 4.14 Installation Check List
CAUTION
POTENTIAL HAZARD IN THE EVENT OF INTERNAL FAILURE
Risk of personal injury when the active filter is not properly closed.
Before applying power, ensure all safety covers are in place and securely fastened.
MG90V302
Operating Instructions
Danfoss A/S © 09/2014 All rights reserved.
4
4
29
