Applications and Basic Prog...
0-12 This Set-up Linked to
Option: Function:
Set-up 1. A switch between Set-up 1 and Set-up
2 during operation is now possible.
[0] Not linked
*
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
0-13 Readout: Linked Set-ups
Range: Function:
0 [0 - View a list of all the set-ups linked by means of
*
255 ] 0-12 This Set-up Linked to. The parameter has one
index for each parameter set-up. The parameter
value displayed for each index represents which
set-ups are linked to that parameter set-up.
Index
0
1
2
3
4
Table 6.7 Example: Set-up 1 and Set-up 2 are
linked
0-14 Readout: Edit Set-ups / Channel
Range: Function:
0 [-2147483648 - View the setting of parameter 0-11 Edit Set-
*
2147483647] up for each of the 4 different
communication channels. When the
number is displayed as a hex number, as it
is in the LCP, each number represents 1
channel.
Numbers 1-4 represent a set-up number; F
means factory setting; and A means active
set-up. The channels are, from right to left:
LCP, FC bus, USB, HPFB1-5.
Example: The number AAAAAA21h means
the following:
•
The frequency converter selected
Set-up 2 via a fieldbus channel.
This selection is reflected in
parameter 0-11 Edit Set-up.
•
A user selected Set-up 1 via the
LCP.
•
All other channels are using the
active set-up.
MG90V302
Operating Instructions
LCP value
{0}
{1,2}
{1,2}
{3}
{4}
Danfoss A/S © 09/2014 All rights reserved.
6.4.3 0-2* LCP Display
Define the variables displayed in the LCP.
NOTICE
Refer to 0-37 Display Text 1, 0-38 Display Text 2 and
0-39 Display Text 3 for information on how to write
display texts.
0-20 Display Line 1.1 Small
Option:
[0] None
[1501] Running Hours
[1600] Control Word
[1603] Status Word
[1630] DC Link Voltage
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1639] Control Card Temp.
[1660] Digital Input
[1666] Digital Output [bin]
[1671] Relay Output [bin]
[1680] Fieldbus CTW 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
Function:
Select a variable for display in
line 1, left position.
No display value selected.
Running hours meter of the
unit.
Present control word
Present status word.
Intermediate circuit voltage in
the unit.
Present heat sink temperature
of the unit. The cut-out limit is
95 ±5 °C; cutting back in occurs
at 70 ±5 °C.
Percentage load of the inverters.
Nominal current of the unit.
Maximum current of the unit.
Temperature of the control card.
Signal states form the 6 digital
terminals (18, 19, 27, 29, 32 and
33). There are 16 bits in total,
but only 6 of them are used.
Input 18 corresponds to the
leftmost of the used bits. Signal
low=0; Signal high=1.
Binary value of all digital
outputs.
Binary value of the relay
outputs.
Control word (CTW) received
from the bus master.
Extended Fieldbus communi-
cation option status word.
Control word (CTW) received
from the bus master.
One or more alarms in a hex
code.
One or more alarms in a hex
code.
One or more warnings in a hex
code.
One or more warnings in a hex
code.
One or more status conditions
in a hex code.
