6.12.5 14-** Special Functions

Par. Parameter description
No. #
14-2* Trip Reset
14-20 Reset mode
14-21 Automatic restart time
14-22 Operation mode
14-23 Typecode setting
14-28 Production settings
14-29 Service code
14-5* Environment
14-50 RFI filter
14-53 Fan monitor
14-54 Bus partner

6.12.6 15-** FC Information

Par. Parameter description
No. #
15-0* Operating Data
15-00 Operating hours
15-01 Running hours
15-03 Power up's
15-04 Over temp's
15-05 Over volt's
15-07 Reset running hours counter
15-1* Data Log Settings
15-10 Logging source
15-11 Logging interval
15-12 Trigger event
15-13 Logging mode
15-14 Samples before trigger
15-2* Historic Log
15-20 Historic log: Event
15-21 Historic log: Value
15-22 Historic log: Time
15-3* Fault Log
15-30 Fault log: Error code
15-31 Fault log: Value
15-32 Fault log: Time
15-4* Unit Identification
15-40 FC type
15-41 Power section
15-42 Voltage
15-43 Software version
15-44 Ordered typecode string
15-45 Actual typecode string
15-46 Unit ordering number
15-47 Power card ordering number
15-48 LCP ID number
15-49 SW ID control card
MG90V302
Operating Instructions
Default value
[0] Manual reset
10 s
[0] Normal operation
null
[0] No action
0 N/A
[1] On
[1] Warning
1 N/A
Default value
0 h All set-ups
0 h All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
[0] Do not reset All set-ups
0 2 set-ups
ExpressionLimit 2 set-ups
[0] False
[0] Log always 2 set-ups
50 N/A 2 set-ups
0 N/A All set-ups
0 N/A All set-ups
0 ms All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 s All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
