5-10 Terminal 18 Digital Input
Option: Function:
[100] Follower AF Do not program this setting. It is done
#2 Run automatically for paralleling. See
Feedback parameter 300-40 Master Follower Selection
and parameter 300-41 Follower ID for more
information about paralleling.
[101] Sleep The filter goes into sleep mode at light duty
to save energy.
5-11 Terminal 19 Digital Input
Option: Function:
[0] No Operation Functions are described under 5-1* Digital
*
Inputs
5-12 Terminal 27 Digital Input
Option: Function:
[0] No Operation Functions are described under 5-1* Digital
*
Inputs
5-13 Terminal 29 Digital Input
Option: Function:
[0] No Operation Functions are described under 5-1* Digital
*
Inputs
5-16 Terminal X30/2 Digital Input
Option: Function:
[0] No operation Functions are described under 5-1* Digital
*
Inputs
5-17 Terminal X30/3 Digital Input
Option: Function:
[0] No operation Functions are described under 5-1* Digital
*
Inputs
5-18 Terminal X30/4 Digital Input
Option: Function:
[0] No operation Functions are described under 5-1* Digital
*
Inputs
5-19 Terminal 37 Safe Torque Off (STO)
Function Number PTC
No Function [0] -
Safe Torque Off [1]* -
(STO) Alarm
Table 6.9 Overview of Functions, Alarms and Warnings
6.5.3 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
terminal 27 in parameter 5-01 Terminal 27 Mode, and set
the I/O function for terminal 29 in parameter 5-02 Terminal
MG90V302
Operating Instructions
29 Mode. These parameters cannot be adjusted while the
unit is running.
5-30 Terminal 27 Digital Output
Option:
[0] No operation
[1] Control ready
[2] Unit ready
[4] Enable / no
warning
[5] Running
[9] Alarm
[10] Alarm or
warning
[12] Current limit
[21] Thermal
warning
[22] Ready,no
thermal W
[24] Ready, voltage
OK
[26] Bus OK
[55] Pulse output
[122] No alarm
[125] Hand mode
Relay
-
[126] Auto mode
safe torque off
[A68] [152] AF sleeping
5-31 Terminal 29 Digital Output
Option:
[0] No operation Functions are described under parameter
*
Danfoss A/S © 09/2014 All rights reserved.
Function:
Default for all digital outputs and relay
outputs.
The control card is ready. E.g.: Feedback
from a unit where the control is supplied
by an external 24 V (MCB 107) and the
main power to the unit is not detected.
The unit is ready for operation and applies
a supply signal on the control board.
Ready for operation. No start or stop
command is been given (start/disable). No
warnings are active.
The motor is running and shaft torque
present.
An alarm activates the output. There are
no warnings.
An alarm or a warning activates the
output.
The motor current is outside the range set
in 4-18 Current Limit. The active filter
current is at the limit.
The thermal warning turns on when the
temperature exceeds the limit in the
active filter.
The unit is ready for operation and there
is no overtemperature warning.
The unit is ready for operation and the
mains voltage is within the specified
voltage range.
Active communication (no time-out) via
the serial communication port.
Output is high when the unit is in Hand
on mode (as indicated by the LED light
above [Hand on]).
Function:
group 5-3* Digital Outputs
