6.12.8 300-** AF Settings

NOTICE
Except for parameter 300-10 Active Filter Nominal Voltage, it is not recommended to change the settings in this
parameter group.
Par. No. # Parameter description
300-0* General Settings
300-00 Harmonic cancellation mode
300-01 Compensation priority
300-08 Lagging reactive current
300-1* Network Settings
6 6
300-10 Active filter nominal voltage
300-2* CT Settings
300-20 CT primary rating
300-22 CT nominal voltage
300-24 CT sequence
300-25 CT polarity
300-26 CT placement
300-29 Start auto CT detection
300-3* Compensation
300-30 Compensation points
300-35 Cosphi reference
300-4* Paralleling
300-40 Master follower selection
300-41 Follower ID
300-42 Number of follower AFs
300-5* Sleep Mode
300-50 Enable sleep mode
300-51 Sleep mode trig source
300-52 Sleep mode wake up trigger
300-53 Sleep mode sleep trigger

6.12.9 301-** AF Readouts

Par. No. # Parameter description
301-0* Output Currents
301-00 Output current [A]
301-01 Output current [%]
301-1* Unit Performance
301-10 THD of current [%]
301-11 Estimated THD of voltage [%]
301-12 Power factor
301-13 Cosphi
301-14 Leftover currents
301-2* Mains Status
301-20 Mains current [A]
301-21 Mains frequency
301-22 Fund. mains current [A]
68
Operating Instructions
Default value
[0] Overall
[0] Harmonics
[0] Disabled
ExpressionLimit
ExpressionLimit
342 V
[0] L1, L2, L3
[0] Normal
[1] Load Current
[0] Off
0.0 A
0.500 N/A
[2] Not Paralleled
1 N/A
1 N/A
null
[0] Mains current
ExpressionLimit
80 %
Default value
0.00 A
0.0 %
0.0 %
0.0 %
0.00 N/A
0.00 N/A
0.0 A
0 A
0 Hz
0 A
