Instructions concerning connection cables.

Wire size range: AWG 12÷30, (solid/stranded) (UL).
Use 60/75°C copper (Cu) conductor only.
We recommend the use of separate power supplies for the safety module and for
other electrical power equipment (electric motors, inverters, frequency converters)
or other sources of disturbance.
Cables used for connections of longer than 50m must have a cross-section of at
least 1mm2 (AWG16).
Connections of each single MOSAIC system unit are listed in the table below:
TERMINAL SIGNAL
1 24VDC
2 MASTER_ENABLE1
3 MASTER_ENABLE2
4 GND
5 OSSD1_A
6 OSSD1_B
7 RESTART_FBK1
8 OUT_STATUS1
9 OSSD2_A
10 OSSD2_B
11 RESTART_FBK2
12 OUT_STATUS2
13 OUT_TEST1
14 OUT_TEST2
15 OUT_TEST3
16 OUT_TEST4
17 INPUT1
18 INPUT2
19 INPUT3
20 INPUT4
21 INPUT5
22 INPUT6
23 INPUT7
24 INPUT8
12
Master M1
TYPE DESCRIPTION
- 24VDC power supply
Input Master Enable 1
Input Master Enable 2
- 0VDC power supply
Output
Static output 1
Output
Input Feedback/Restart 1
Output Programmable digital output
Output
Static output 2
Output
Input Feedback/Restart 2
Output Programmable digital output
Output Short circuit detected output
Output Short circuit detected output
Output Short circuit detected output
Output Short circuit detected output
Input Digital input 1
Input Digital input 2
Input Digital input 3
Input Digital input 4
Input Digital input 5
Input Digital input 6
Input Digital input 7
Input Digital input 8
MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
OPERATION
Input ("type B" according to
Input ("type B" according to
PNP active high
PNP active high
Input according to EN 61131-2
PNP active high
PNP active high
PNP active high
Input according to EN 61131-2
PNP active high
PNP active high
PNP active high
PNP active high
PNP active high
Input according to EN 61131-2
Input according to EN 61131-2
Input according to EN 61131-2
Input according to EN 61131-2
Input according to EN 61131-2
Input according to EN 61131-2
Input according to EN 61131-2
Input according to EN 61131-2
8540780 • 25th June 2012 • Rev.15
-
EN 61131-2 )
EN 61131-2 )
-
