MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC

FIELDBUS INPUT

Element that permits insertion of a non-safety input
whose status is modified via the fieldbus.
Up to 8 virtual inputs can be inserted and the bit
on which status is to be modified must be selected
for each.
They are represented with one byte on the fieldbus.
(For more detailed information, consult the fieldbus
manual on the MSD CD-ROM).
WARNING: the FIELDBUS INPUT is NOT a safety input.

COMMENTS

This allows a description to be entered and placed
in any point of the diagram.

TITLE

Automatically adds the name of the manufacturer, the
designer, the project name and the CRC.
8540780 • 25th June 2012 • Rev.15 75
