Reer MOSAIC Master M1 Installation And Use Manual page 18

TERMINAL SIGNAL
1 24VDC
4 GND
5 OSSD1_A
6 OSSD1_B
7 FBK_K1_K2_1
9 A_NC1
10 B_NC1
13 A_NO11
14 B_NO11
15 A_NO12
16 B_NO12
11 A_NC2
12 B_NC2
17 OSSD2_A
18 OSSD2_B
19 FBK_K1_K2_2
21 A_NO21
22 B_NO21
23 A_NO22
24 B_NO22
TERMINAL SIGNAL
1 24VDC
4 GND
5 OSSD1_A
6 OSSD1_B
7 FBK_K1_K2_1
9 A_NC1
10 B_NC1
13 A_NO11
14 B_NO11
15 A_NO12
16 B_NO12
18
MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
MR4
TYPE DESCRIPTION
- 24VDC power supply
- 0VDC power supply
Input
Control ZONE 1
Input
Output Feedback K1K2 ZONE 1
Output
NC contact ZONE 1
Output
Output
NO1 contact ZONE 1
Output
Output
NO2 contact ZONE 1
Output
Output
NC contact ZONE 2
Output
Input
Control ZONE 2
Input
Output Feedback K1K2 ZONE 2
Output
NO1 contact ZONE 2
Output
Output
NO2 contact ZONE 2
Output
Table 8
MR2
TYPE DESCRIPTION
- 24VDC power supply
- 0VDC power supply
Input
Control ZONE 1
Input
Output Feedback K1K2 ZONE 1
Output
NC contact ZONE 1
Output
Output
NO1 contact ZONE 1
Output
Output
NO2 contact ZONE 1
Output
Table 9
OPERATION
-
-
PNP active high
PNP active high
OPERATION
-
-
PNP active high
8540780 • 25th June 2012 • Rev.15
