PRODUCT COMPOSITION

The MOSAIC M1is supplied with:
• CD-ROM containing the free MSD SW, this PDF multi-language handbook and
other product literature.
• Multi-language installation sheet.
NB: the rear panel MSC connector and MCM memory can be ordered separately as
accessories.
The expansion units are supplied with:
• Multilingual Installation sheet.
• Rear panel MSC connector (not present in the MR2 and MR4 which are
connected via terminal blocks only).
NB: to install an expansion unit (excluding relays) you will need the MSC connector
supplied with the unit plus another MSC for the connection to the M1. This can be
ordered separately as an accessory.
