Figure 35. Lqfp100, 14 X 14 Mm, 100-Pin Low-Profile Quad Flat Package - STMicroelectronics STM32L151RE Manual

Package information
Table 66. LQPF100, 14 x 14 mm, 100-pin low-profile quad flat package mechanical
Symbol
E3
e
L
L1
k
ccc
1. Values in inches are converted from mm and rounded to 4 decimal digits.

Figure 35. LQFP100, 14 x 14 mm, 100-pin low-profile quad flat package

1. Dimensions are in millimeters.
118/134
data (continued)
millimeters
Min Typ
- 12.000
- 0.500
0.450 0.600
- 1.000
0.0° 3.5°
- -
recommended footprint
DocID025433 Rev 8
STM32L151xE STM32L152xE
Max Min
- -
- -
0.750 0.0177
- -
7.0° 0.0°
0.080 -
(1)
inches
Typ Max
0.4724 -
0.0197 -
0.0236 0.0295
0.0394 -
3.5° 7.0°
- 0.0031
