Electrical characteristics
Designing hardened software to avoid noise problems
EMC characterization and optimization are performed at component level with a typical
application environment and simplified MCU software. It should be noted that good EMC
performance is highly dependent on the user application and the software in particular.
Therefore it is recommended that the user applies EMC software optimization and
prequalification tests in relation with the EMC level requested for his application.
Software recommendations
The software flowchart must include the management of runaway conditions such as:
•
Corrupted program counter
•
Unexpected reset
•
Critical data corruption (control registers...)
Prequalification trials
Most of the common failures (unexpected reset and program counter corruption) can be
reproduced by manually forcing a low state on the NRST pin or the oscillator pins for 1
second.
To complete these trials, ESD stress can be applied directly on the device, over the range of
specification values. When unexpected behavior is detected, the software can be hardened
to prevent unrecoverable errors occurring (see application note AN1015).
Electromagnetic Interference (EMI)
The electromagnetic field emitted by the device are monitored while a simple application is
executed (toggling 2 LEDs through the I/O ports). This emission test is compliant with
IEC 61967-2 standard which specifies the test board and the pin loading.
Symbol Parameter
S Peak level
EMI
78/129

Table 38. EMI characteristics

Conditions
0.1 to 30 MHz
= 3.3 V,
V
DD
= 25 °C,
T
30 to 130 MHz
A
LQFP100 package
130 MHz to 1GHz
compliant with IEC
61967-2
SAE EMI Level
DocID17659 Rev 10
STM32L151x6/8/B, STM32L152x6/8/B
Monitored
4 MHz
frequency band
voltage
Range 3
Max vs. frequency range
16 MHz
32 MHz
voltage
voltage
Range 1
Range 2
3 -6
18 4
15 5
2.5 2
Unit
-5
-7 dBµV
-7
1 -
