Package characteristics

Figure 40. UFBGA100 7 x 7 x 0.6 mm 0.5 mm pitch, ultra thin fine-pitch ball grid array

1. Drawing is not to scale.

Table 67. UFBGA100 7 x 7 x 0.6 mm 0.5 mm pitch, ultra thin fine-pitch ball grid array

Symbol
A
A1
A2
A3
A4
b
D
D1
E
E1
e
F
ddd
114/129
package outline
package mechanical data
millimeters
Min Typ
- -
0.05 0.08
0.4 0.45
0.08 0.13
0.27 0.32
0.2 0.25
6.95 7
5.45 5.5
6.95 7
5.45 5.5
- 0.5
0.7 0.75
- -
DocID17659 Rev 10
STM32L151x6/8/B, STM32L152x6/8/B
Max Min
0.6 -
0.11 0.002
0.5 0.0157
0.18 0.0031
0.37 0.0106
0.3 0.0079
7.05 0.2736
5.55 0.2146
7.05 0.2736
5.55 0.2146
- -
0.8 0.0276
0.1 -
(1)
inches
Typ Max
- 0.0236
0.0031 0.0043
0.0177 0.0197
0.0051 0.0071
0.0126 0.0146
0.0098 0.0118
0.2756 0.2776
0.2165 0.2185
0.2756 0.2776
0.2165 0.2185
0.0197 -
0.0295 0.0315
- 0.0039
