Package characteristics
Figure 41. TFBGA64 - 5.0x5.0x1.2 mm, 0.5 mm pitch, thin fine-pitch ball grid array
1. Drawing is not to scale.
Table 68. TFBGA64 5.0x5.0x1.2 mm, 0.5 mm pitch thin fine-pitch ball grid array
Symbol
A
A1
A2
A4
b
D
D1
E
E1
e
F
ddd
116/129
package outline
package mechanical data
millimeters
Min
Typ
-
-
0.150
-
-
0.200
-
-
0.250
0.300
4.850
5.000
-
3.500
4.850
5.000
-
3.500
-
0.500
-
0.750
-
-
DocID17659 Rev 10
STM32L151x6/8/B, STM32L152x6/8/B
Max
Min
1.200
-
-
0.0059
-
-
0.600
-
0.350
0.0098
5.150
0.1909
-
-
5.150
0.1909
-
-
-
-
-
-
0.080
-
(1)
inches
Typ
Max
-
0.0472
-
-
0.0079
-
-
0.0236
0.0118
0.0138
0.1969
0.2028
0.1378
-
0.1969
0.2028
0.1378
-
0.0197
-
0.0295
-
-
0.0031
