AMI Codes-II
Program List and Explanations
5.3.2.1
5.3.3.1
5.3.4
5.3.4.1
5.3.4.2
5.3.4.3
A-96.250.571 / 050517
Function = Fieldbus:
The relay will be switched via the Profibus input. No further param-
eters are needed.
Function = End of Batch
This function is only available on relay 2. It is used to communicate
with canal switching instruments from third-party suppliers. The
relay closes for 1 sec. after each valid measurement. If End of
Batch is selected, no further selection is possible.
Input: The functions of the relays and signal outputs can be de-
fined depending on the position of the input contact, i.e. no function,
closed or open.
Active: Define when the input should be active:
No: Input is never active.
When closed Input is active if the input relay is closed
When open: Input is active if the input relay is open
Signal Outputs: Select the operation mode of the signal outputs
when the relay is active:
Cont.: Signal outputs continue to issue the measured
value.
Hold: Signal outputs issue the last valid measured value.
Measurement is interrupted. Errors, except fatal
errors, are not issued.
Off: Set to 0 or 4 mA respectively. Errors, except fatal
errors, are not issued.
Output/Control: (relay or signal output):
Cont.: Controller continues normally.
Hold: Controller continues on the last valid value.
Off: Controller is switched off.
93
