AMI Codes-II
Troubleshooting
Error
E011
Temp. shorted
E012
Temp. disconnected
E013
Case Temp. high
E014
Case Temp. low
E017
Control Timeout
E018
Reagent Pump
E019
Photometer not con-
nected
E020
Photometer dirty
E021
DIS. invalid
E022
Reagent empty
E023
Cleaning solution
E024
Input active
E026
IC LM75
E028
Signal output open
68
Description
Corrective action
– check wiring of temperature sensor, see
Connection Diagram, p. 26
– check temperature sensor
– check wiring of temperature sensor, see
Connection Diagram, p. 26
– check temperature sensor
– check case/environment temperature
– check programmed value in menu
5.3.1.5, p. 88
– check case/environment temperature
– check programmed value in menu
5.3.1.6, p. 88
– check control device or programming in
Installation, Relay contact, Relay 1/2
5.3.2 and 5.3.3, p. 88
– shut off power
– check wiring, see
p. 26
– shut off power
– check wiring of photometer, see
Connection Diagram, p. 26
– check process,
– clean photometer, see
Photometer, p. 54
– This error appears after start-up and will
disappear after the first valid
measurement is finished.
– refill reagents, see
Reagents, p. 43
– refill cleaning solution
– See If Fault Yes is programmed in Menu
5.3.4, p. 93
– call service
– check wiring on signal outputs 1 and 2
Connection Diagram,
Cleaning the
Refill or replace
A-96.250.571 / 050517
