AMI Codes-II
Program List and Explanations
5.3.1.4
5.3.1.4.1
5.3.1.4.2
5.3.1.5
5.3.1.6
5.3.2 and 5.3.3
88
Sample Temperature: Only available if pH option is installed.
Define the measuring value, which should issue an alarm high
respectively low.
Alarm High: If the sample temperature rises above the
programmed value E007 is issued.
Range: 30–70 °C
Alarm Low: If the sample temperature falls below the programmed
value E008 is issued.
Range: 0–20 °C
Case Temp. high: Set the alarm high value for temperature of
electronics housing. If the value rises above the programmed value
E013 is issued.
Range: 30–75 °C
Case Temp. low: Set the alarm low value for temperature of
electronics housing. If the value falls below the programmed value
E014 is issued.
Range: -10 to + 20 °C
Relay 1 and 2: The contacts can be set as normally open or
normally closed with a jumper. See
The function of the relay contacts 1 and 2 is defined by the user.
NOTICE: The navigation in the menu <Relay 1> and <Relay 2>
is equal. For reason of simplicity only the menu numbers of
Relay 1 are used in the following.
1 First select the functions as:
- Limit upper/lower,
- Control upwards/downwards,
- Timer
- Fieldbus
- End of Batch (relay 2 only)
2 Then enter the necessary data depending on the selected func-
tion.
Relay 1 and 2, p. 29.
A-96.250.571 / 050517
