AMI Codes-II
Maintenance
Dismount
pump tubes
60
The pump tube can easily be dismounted and mounted.
Proceed as follows:
1 Switch off the instrument according to instructions in
Operation for Maintenance, p. 43
2 Open the occlusion frames (B) by turning it counter-clockwise.
3 Remove the occlusion frame (B) from the rotor (C) by pulling
the complete occlusion frame out of the holder.
4 Dismount all reagent tubes from the occlusion frame.
5 Exchange the occlusion frame.
6 Install all reagent tubes.
7 Lock the occlusion frames.
8 Start fill system.
A
Pump housing
B
Occlusion frame open
A
C
Rotor
B
D
Pump tube
C
E
Pump inlet
F
Pump outlet
D
E
F
A-96.250.571 / 050517
