Specifications; Dgeneral; Dreceiver - Icom IC-R8600 Instruction Manual

D General
• Frequency coverage:
USA
France
Other than above
• Receiving modes:
• Number of memory channels:
• Power supply requirement:
• Grounding system:
• Operating temperature range:
• Frequency stability:
• Antenna connectors:
• Frequency resolution:
• Power consumption:
• Dimensions (projections not included): 220 (W)×90 (H)×230 (D) mm, 8.7 (W)×3.5 (H)×9.1 (D) in
• Weight (approximately):
D Receiver
• Receive system:
• Sampling frequency:
• Intermediate frequencies:

SPECIFICATIONS

0.010000 ~ 821.999999 MHz*
851.000000 ~ 866.999999 MHz
896.000000 ~ 3000.000000 MHz
0.135700 ~ 0.137800 MHz
1.810000 ~ 1.850000 MHz
3.500000 ~ 3.800000 MHz
7.000000 ~ 7.200000 MHz
10.100000 ~ 10.150000 MHz
14.000000 ~ 14.350000 MHz
18.068000 ~ 18.168000 MHz
21.000000 ~ 21.450000 MHz
24.890000 ~ 24.990000 MHz
28.000000 ~ 29.700000 MHz
50.000000 ~ 52.000000 MHz
144.000000 ~ 146.000000 MHz
430.000000 ~ 440.000000 MHz
1240.000000 ~ 1300.000000 MHz
2300.000000 ~ 2450.000000 MHz
0.010000 ~ 3000.000000 MHz*
*Some frequency ranges are not guaranteed.
SSB, CW, FSK, AM, FM, WFM and DIGITAL ( D-STAR, P25, NXDN,
2000 (in 100 groups)
+ 400 (Scan edges: 100 (50 pairs), Auto Memory Write: 200 and Scan Skip: 100)
13.8 V DC (±15%)
Negative
–10°C to +60°C, +14°F to +140°F
Less than ±0.5 ppm
[ANT1]
Frequency range 10 kHz ~ 3000 MHz 10 kHz ~ 30 MHz 10 kHz ~ 30 MHz
Impedance 50 Ω Unbalanced 50 Ω Unbalanced 500 Ω Unbalanced
Connector N type
1 Hz (minimum)
Standby 1.8 A
Maximum audio 2.0 A
4.3 kg, 9.5 Ib
0.010000 ~ 29.999999 MHz Direct sampling
30.000000 ~ 1099.999999 MHz Double superheterodyne
1100.000000 ~ 3000.000000 MHz Triple superheterodyne
122.88 MHz
Receive frequency (MHz)
0.010000 ~ 29.999999
30.000000 ~ 499.999999
500.000000 ~ 1099.999999
1100.000000 ~ 1499.999999
1500.000000 ~ 3000.000000
14-1
dPMR and DCR)
[ANT2]
SO-239
1st IF (MHz) 2nd IF (MHz) 3rd IF (MHz)
– –
778.7 46.35
278.7 46.35
900 ~ 500.00001 278.7
1000 ~ 500 278.7
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
[ANT3]
16
RCA
17
18
19
20
21
–
–
–
46.35
46.35
