ABOUT THE INSTRUCTIONS

This manual is described in the following manner.
" " (Quotation marks):
Used to indicate icons, setting items, and screen titles
displayed on the screen.
The screen titles are also indicated in uppercase
letters. (Example: FUNCTION screen)
[ ] (brackets):
Used to indicate keys.
Routes to the set modes and setting screens
Routes to the Set mode, setting screen and the setting
items are described in the following manner.
» SET > Time Set > Date
MENU
Instruction example
D About the touch operation
In the manual, the touch operation is described as
shown below.
Touch
If the display is touched briefly, one short beep
sounds.
Touch for 1 second
If the display is touched for 1 second, one
short and one long beep sound.
D Touch screen precautions
• The touch screen may not properly work when the
LCD protection film or sheet is attached.
• Touching the screen with your finger nails, sharp
topped object and so on, or touching the screen
hard may damage it.
• Tablet PC's operations such as flick, pinch in and
pinch out cannot be performed on this touch screen.
D Touch screen maintenance
• If the touch screen becomes dusty or dirty, wipe it
clean with a soft, dry cloth.
• When you wipe the touch screen, be careful not to
push it too hard or scratch it with your finger nails.
Otherwise you may damage the screen.
Detailed instruction
1. Push .
MENU
Push
• The MENU screen opens.
2. Touch [SET].
MENU screen
• The SET screen opens.
3. Rotate
push .
SET screen
4. Rotate to select "Date," then push
DATE/TIME screen
5. Touch [+] or [–] to set the date.
6. Touch [SET] to save the entry.
DATE screen
iv
to select "Time Set," and then
.
