Wall Mount Installation

Included in Package
Description
Valcom Digital Clock
Digital Clock Wall Housing
6-19x1/2 screw
6-32x1 screw
Included in Wiring Kit (D-PK-3-110-S or D-PK-3-24-S)
Power/grounding wires
and connector
PLEASE NOTE: A user will also have to provide a Phillips-head screwdriver, a small flat-blade screwdriver, a single gang box, any equipment needed to install
the gang box, and any additional wiring needed to extend the signal, power, or ground cables. You may also need a 1/4 inch drill, 4 #8x1.5 self-tapping
screws, and 4 wall anchors for those screws if you decide not to attach the clock directly to the gang box.
If any of the items listed in the wiring kit are missing, you may contact Valcom and order a
replacement kit.
Quantity
1
1
4
4
1
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
110V
or
P. 540-563-2000
F. 540-362-9800
www.valcom.com
24V
4
