Double Mount Installation
13) Attach the signal and power wires from your kit to the wires you threaded through the poles. Consult
the diagrams below for additional help, or see the sections of this manual labeled "3-Wire Synchronous
(Sync-Wire) Communication Wiring Information" or "2-Wire Digital Communication Wiring Information"
for additional details, depending on your system.
Please refer to the wiring guide
3-Wire Sync
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
13
To next
clock
A2/B2/C2
Gang
Box
CLOCK 2
Yellow
Orange
2-Wire Digital
P. 540-563-2000
F. 540-362-9800
www.valcom.com
Input A
A1/B1/C1
V-VCU
Input B
110VAC
CLOCK 1
Yellow
Orange
18
19
25
