Valcom V-D11025B Installation Manual page 42

Manual Controls (V-D110XXB Only)
The numbers shown on the left are examples. Going down the list and entering every one
of the examples exactly as shown will cause the clock to malfunction or use incorrect data.
Program your clock setting based off of the instructions in the description on the right.
21-- 14
22--00
23--30
24--05
30- 1
31-- 14
32--00
33--30
Setting 21 - Once a Day Pulse Output - Set Hour
This setting only appears if "8" was selected under Setting 20. Press the bottom
button to scroll from 00 to 23. For example, a value of 13 is the same as 1:00PM.
Set to 0 by default.
Setting 22 - Once a Day Pulse Output - Set Minutes
This setting only appears if "8" was selected under Setting 20. Press the bottom
button to scroll from 00 to 59. Set to 0 by default.
Setting 23 - Once a Day Pulse Output - Set Seconds
This setting only appears if "8" was selected under Setting 20. Press the bottom
button to scroll from 00 to 59. Set to 0 by default.
Setting 24 - Once a Day Pulse Output - Set Pulse Duration
This setting only appears if "8" was selected under Setting 20. Press the bottom
button to scroll from 00 to 99. For example, a value of 98 will set a pulse
duration of 1 minute and 38 seconds. Set to 3 by default.
Setting 30 - Set Sync Wire Time Input Type
Allows the user to configure the sync wire type used as an Input.
Press the bottom button to scroll from 1 to 9 or d. These numbers correspond to
the different protocols listed below. Set to 8 by default.
d - Disable Auxiliary Input
03 - 58 Minute Correction (3)
06 - National Time/Rauland
Setting 31 - Once a Day Pulse Input - Clock #2 Circuit - Set Hour
This setting only appears if "8" was selected under Setting 20. Press the bottom
button to scroll from 00 to 23. For example, a value of 13 is the same as 1:00PM.
Set to 0 by default.
Setting 32 - Once a Day Pulse Input - Clock #2 Circuit - Set Minutes
This setting only appears if "8" was selected under Setting 20. Press the bottom
button to scroll from 00 to 59. Set to 0 by default.
Setting 33 - Once a Day Pulse Input - Clock #2 Circuit - Set Seconds
This setting only appears if "8" was selected under Setting 20. Press the bottom
button to scroll from 00 to 59. Set to 0 by default.
01 - 58 Minute Correction (1)
04 - 58 Minute Correction (4)
07 - Dukane Digital
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
02 - 58 Minute Correction (2) 09 - Once a Day Pulse
05 - 59 Minute Correction
08 - Rauland Digital
P. 540-563-2000
F. 540-362-9800
www.valcom.com
42
