Inputs - System-Side - Sync-Wire 110VAC (V-D110XXB Only)
Valcom Master Clock
10 Amp Contact Rating
Clock Circuit
27
26
or
24
23
115 VAC
or*
27 26 25 24 23 22
Neutral
White
Power
Black
Reset
Yellow
Green
Ground
Neutral
J1-1
Reset
J1-2
Power
Black
Neutral
White
Green
Ground
Neutral
White
Power
Black
Reset
Yellow
Green
Ground
27 26 25 24 23 22
Clock Circuit 2
V-D11025B or V-D11040B
Red & Blue Wires are NOT provided by Valcom
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
Clock Circuit 1
* "or" means one pair of ports or
the other. You cannot, for instance,
use port 23 for reset and 27 for
power, nor can you use 26 for reset
and 24 for power. You must use
the pair 24 AND 23 or the pair
26 AND 27
V-A11012 or V-A11016
V-A11012B or V-A11016B
V-A11012 or V-A11016
V-A11012B or V-A11016B
P. 540-563-2000
F. 540-362-9800
www.valcom.com
31
