CYBEX VR2 Owner's And Service Manual page 15

Arm Extension - Product No. 4540
Machine Weight Weight Stack
433 lbs.
197 kg
• The input arm automatically adjusts to accommodate varying forearm
lengths and a neutral grip position allows full extension without shoulder
rotation.
• The arm pad is angled for stability and the axis or pivot point is properly
positioned to allow alignment of the elbow joint.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Ab Crunch - Product No. 4705
Machine Weight Weight Stack
407 lbs.
185 kg
• Pivot point posterior to the spine creates a downward arc of motion
matching spinal flexion, creating an improved path for abdominal isolation.
• ROM adjustment via seat height manipulation with fine-tuning made
possible by moving back of forward slightly in the seat.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Back Extension - Product No. 4713, 4712, 4711
Machine Weight Weight Stack
606 lbs.
275 kg
• Provides exceptional alignment and comfort for users of all sizes promoting
coordinated function of hip and lower back muscle consistent with proper
lifting technique.
• Advanced RLD design maintains integrity of the resistance profile.
o
• RLD positions are 10 apart with start and end phased by 5
protection.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Torso Rotation - Product No. 4715
Machine Weight Weight Stack
462 lbs.
211 kg
• Innovative design that applies resistance securely through the lower body
for efficiency.
• Upper torso assists with stabilization while eliminating the possibility of
dizziness by keeping the head stationary.
• "Slackless" drive mechanism for immediate resistance.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Cybex VR2 Owner's Manual
205 lbs. inches = 36 W x 51 L x 55 H
93 kg cm = 92 W x 130 L x 140 H
205 lbs. inches = 42 W x 42 L x 55 H
93 kg cm = 107 W x 107 L x 140 H
305 lbs. inches = 41 W x 50 L x 61 H
139 kg cm = 105 W x 127 L x 155 H
205 lbs. inches = 28 W x 43 L x 67 H
93 kg cm = 72 W x 110 L x 171 H
Size
Size
Size
o
for maximum
Size
Technical
Specifications
Page 1-9
